Data Center Tour

The Datacenter  in Dallas, Texas, offering complete redundancy in power, HVAC, fire suppression, network connectivity, and security. With over 53,000 sq ft of raised floor between the two facilities, The Planet has an offering to fit any need.  The datacenter facility sits atop multiple power grids driven by TXU electric, with PowerWare UPS battery backup power and dual diesel generators onsite.

Our HVAC systems are condenser units by Data Aire to provide redundancy in cooling coupled with nine managed backbone providers. Twelve more third party backbone providers are available in the building via cross connect. Fire suppression includes a pre-action dry pipe system including VESDA (Very Early Smoke Detection Apparatus) with over 700 smoke detectors between the two facilities.

60,000 sq. ft. facility
35,000 sq. ft. of raised floor
(21) 26-ton Data Air AC units
Very Early Smoke Detection Apparatus (VESDA)
Pre-action dry pipe sprinkler system
Over 500 smoke detectors in an integrated system
Simplex security badge entry/exit on all doors to facility
Multiple TXU electrical grids
4800 amps of 480v input power
3 main transfer switches
(6) 500KVA Powerware UPS units with 90 batteries per unit
Standalone PDUs at each cabinet row
1-megawatt generator (2000-gallon tank)
1.5-megawatt generator (2200-gallon tank)
DataTrax monitoring software for all data center infrastructure


Lobby / Stairs

The entrance to The Datacenter's offices and datacenter are indicative of the attention paid to security throughout our facilities.

The Datacenter's offices are manned 24/7 by NOC Engineers,
